- Superior quality aluminum alloy construction.
- Energy efficient Electrical Steel Sheet and 99.9% Pure Copper Wire.
- “E” grade varnish insulation to protect from electric shock and voltage fluctuation.
- Aerodynamically designed blades for maximum air delivery.
- High quality paint for superior finishing.
- Packed in strong corrugated cartons with protective thermopore.
General Specifications
| Type |
Blades |
Sweep |
Warranty |
| BLDC Hybrid |
3 |
1400mm |
Yes |
Technical Specifications Inverter
| MODE TYPE |
AC MODE |
DC MODE |
| Rated Mode |
230 VOLT AC |
12 VOLT DC |
| Power Input |
55 WATT |
45 WATT |
| Frequency |
50 Hz |
NA |
| Current in Phase |
0.25 A |
3.75 A |
| Speed @ Full |
1400 rpm |
1350 rpm |
| Speed @ Slow |
610 rpm |
605 rpm |
| Air Dilevery |
100 m3/min |
85 m3/min |
| Power Factor |
0.97 |
NA |
| Service Value |
1.80 m3/min/W |
1.85 m3/min/W |
| Control of Fan |
REMOTE CONTROL |
REMOTE CONTROL |
| Remote Type |
RF REMOTE |
RF REMOTE |
| No. of Speeds |
07 |
07 |
| Winding Material |
Pure Copper |
Pure Copper |
| Timmer |
1H-4H-8H |
1H-4H-8H |
